MOTA Charge Air Cooler Ø97mm (Marine & Industrial)

This reinforced charge air cooler (Intercooler) is the solution for demanding applications requiring reliability and performance.

Tubestack Ø97mm and 261mm long for marine or industrial applications.

It is dismountable to allow for easy cleaning and maintenance. The only parts to be changed are the o-rings!

Part number CAC097-261-2/CN-blue / CAC097-261-2/CN-black.

Technical drawing extract (click here).

Technical data:

Tubestack diametre (Ømm) 97
Tubestack length (mm) 261
Number of passes, cold side 2
Tubes material Copper-nickel (CuNi)
Covers material Brass
Marine Sea water compatible
Cold side connection Ø22mm
Hot side connection Ø68mm
Housing material Powder-coated aluminium
Cooler type Charge Air Cooler (intercooler)
Range Charge Air Cooler (intercooler)
