JMP JPR-S7635 John Deere Replacement Marine Engine Cooling Seawater Pump

Replaces John Deere RE538663, DZ114697, Sherwood P1735X, P1735-02, P1735-05

#JPR-S7635 JMP Marine John Deere Replacement Engine Cooling Raw Water Pump
SKU: JPR-S7635

NOTE 1:
If you are looking for the replacement pump to Sherwood P1719 having spline shaft please refer to part #JPR-S7619. JPR-S7619 has the spline shaft vs #JPR-S7633, #JPR-S7635 having tapered shafts.

NOTE 2:
The only difference between pump #JPR-S7635 and version #JPR-S7633 is the angle of the mounting adapter plate. Please refer to the Dimensional Layout in the product images to view pump #JPR-S7635 mounting adatper angle.

NOTE 3:
The Sherwood Impeller 27000, even though all the dimensions are the same, will not work in the JMP Marine pump since Sherwood makes their version with a threaded insert that is too thick and then bottoms out on the end of the shaft which prevents the complete impeller from fully seating in. If you use the Sherwood impeller you will have a clearance issue with the end cover and the impeller will heat up and melt. For the JMP Marine JPR-S Series pumps you must use impeller #7608-01K

Includes:
JPR-S7635 (John Deere Replacement Pump) QTY:1

Product Information & Specs:

Uses JMP Flexible Impeller p/n: 7608-01K
Port Type: 1.75" Flange
Pump Weight (approx): 13.50 LBS (6.15 KG)
Replaces Genuine John Deere Pump p/n: RE538663, DZ114697
Replaces Sherwood Pump p/n: P1735X, P1735-02, P1735-05
For Engine Model(s): 4045AFM85, 4045SFM85, 6068AFM75, 6068AFM85

Parts are NOT Internally Compatible to Genuine: (Changes made to Impeller, Wear Plate, Cam, Mechanical Seal, Shaft for Better Performance & Quality)

Major Service Kit (All Internal Parts): JSK0133 (*Sold Separately)
Minor Service Kit: JSM0133 or JSM0002 (*Sold Separately)

Product Features:- See Video

Plug & Play System
Impeller Spline Drive (Do Not Need a Key for Impeller Replacement)
Heavy Duty Marine Grade Casting
Marine Grade Shaft (Non-Magnetic)
O-Ring End Cover Packing
High Performance Impeller
High Flow Capacity
Fast Flow Velocity
